Introducing HD Series IC

Our Origin

For the last decade, Synix Semiconductor Technology has cultivated deep industry expertise, extensive networks, and matured technology.

Today

We have evolved from a distributor into innovative designer, developing our own semiconductor devices to meet the dynamic needs of the market.

What are the features of the HD series IC?

Competitive Price

HD series IC is designed to provide affordable price without compromising on performance. We help factories maintain competitive margins while delivering high performance products.

Consistency & Stability

HD series IC and solutions undergo rigorous testing and quality control procedures. Delivering excellent protection mechanisms and EMI performance.

Simplified Circuit Design

HD series IC is engineered for integration efficiency. It reduces your PCB complexity, and minimizes overall material costs for production.

HD GaN Power Series

Our newly released GaN Power series ACDC controllers and Synchronous Rectifiers are specifically designed for modern advanced fast chargers with compact design and prime power delivery efficiency. They'll elevate your charger's charging speed, while allowing you to significantly reduce your manufacturing BOM and overall charger size. These solutions are compatible with a full range of input voltage applications (90-265V) and come at a highly competitive price. If you're interested in learning more, please contact us directly.

Fast Charging

Elevate charging speed with advanced GaN technology

Compact Design

Reduce BOM and overall charger size

Global Compatible

Support full range input voltage (90-265V) applications

ACDC Controller

Part No.	Package	Max Switching Frequency	Standby Power	Transistor	Recommend Application
HD8035X	ESOP-8	118KHz	<75mW	D-GaN HEMT, 1.0Ω/700V	20-30W Charger/Adapter
HD80H35X	ESOP-8	118KHz	<75mW	D-GaN HEMT, 1.0Ω/700V	Constant Power verison of HD8035X
HD8045X	ESOP-7	118KHz	<75mW	D-GaN HEMT, 0.8Ω/700V	30-45W Charger/Adapter
HD8065X	ESOP-7	118KHz	<75mW	E-GaN HEMT, 0.36Ω/700V	45-65W+ Charger/Adapter

Synchronous Rectifier

Part No.	Package	Operation Mode	Transistor	Recommend Application
HD80036X	SOP-8	CCM/DCM/QR	MOSFET, 9.5mΩ/65V	20-30W Charger/Adapter
HD80036XE	SOP-8	CCM/DCM/QR	MOSFET, 9.5mΩ/65V	20-30W Charger/Adapter
HD80038A	SOP-8	CCM/DCM/QR	MOSFET, 12.5mΩ/85V	30-45W Charger/Adapter
HD80031	SOP-8	CCM/DCM/QR	MOSFET, 10mΩ/100V	45W Charger/Adapter
HD80032X	TO-252	CCM/DCM/QR	MOSFET, 10mΩ/100V	45-65W Charger/Adapter

For complete datasheet and sample application, please contact us directly

Note: "X" denotes that this chip is part of a series; the more specific model description can be found in the datasheet.

HD Standard Series

Our HD Standard Series IC offers reliable and cost-effective solutions for standard charger and adapter applications. These controllers provide excellent performance with proven technology. They deliver consistent power delivery and thermal management for various power requirements.

Reliable Performance

Proven technology with excellent stability

Cost Effective

Affordable solution for standard applications

Protection Features

Comprehensive, excellent protection features

ACDC Controller

Part No.	Package	Standby Power	Transistor	Recommend Application
HD3783A	SOP-8	<75mW	BJT, 500mA/750V	5V2A / 12V1A / 24V0.5A
HD8018X	SOP-8	<75mW	BJT, 720mA/700V	20W Charger/Adapter
HD8019X	SOP-8	<75mW	MOSFET, 1.9Ω/650V	20W Charger/Adapter
HD8020X	SOP-8	<75mW	Darlington, 920mA/700V	20W Charger/Adapter
